Fuel supply system: TSI-Direct Injection
Ignition: Positiv Ignition (Electronic Map-controlled Ignition)
Atmospheric/Supercharged: Turbo charged
Fuel type: ROZ 95
Oil capacity in initial fill (I): 4.3
Alternator (A): 110
Battery (Ah/A): 59
Acceleration 0-80 km/h (s): 6.4
Acceleration 80-120 km/h (s) at V: 10.9
Acceleration 1000 m (s): 30.8
Type: 5D
Wheelbase (mm): 2,564
In running order with driver (kg): 1.149
In running order with driver (kg) Front / Rear: 700/449
Maximum weight allowed (kg): 1,570/ 1,660
Maximum weight without brake (kg): 570
Maximum weight w/brake 8% (kg): 1.200
Maximum weight w/brake 12% (kg): 1100
Gearbox type: MQ200-6F GA
Ratios I: 3.769
II: 1.955
III: 1.281
IV: 0.973
V: 0.778
VI: 0.642
VII: -
R: 3.181
Group 1 ratio: 3.789
Group 2 ratio: -
Group 3 ratio: -
Speed 1000 rpm in IV/V (km/h): 31,0/38,7/47,0
Rims: 5JX14 ET38 - 5.5JX15 ET40 - 6.5JX16 ET47 - 7JX17 ET51 - 7JX18 ET51
Tyres: 185/70 R14 88H - 185/65 R15 88H - 185/65 R15 88V - 195/55 R16 91V XL -
215/45 R17 91W XL - 215/40 R18 91W XL
Front suspension: Independent type McPherson - coil springs - hydraulic shock absorber [Variable shock absorber settings (switchable shock absrober): see Commercial Offer]
Rear suspension: Semirigid axle, coil springs and hydraulic shock absorber [Variable shock absorber settings (switchable shock absrober): see Commercial Offer]
Steering System: C-EPS (Column Electric Power System)
Turning diameter (m): 10.6
Brake system: ESC Standard (including HHC, EBA, TCS, EDS, RKA, XDS), ABS Option for no EU6 Motor
Type front and rear brakes: Ventilated front brakes / Drum-Disc brakes in rear axle
Front brakes (mm): Ø 276x24
Rear brakes (mm): Ø 230X9
TSI-Direct Injection
Positiv Ignition (Electronic map-controlled ignition)
Turbo charged
ROZ 95
4.3
110A (8GG)
59Ah (J0S)
Our global range of cars and product specifications varies from country to country. Please, visit your local SEAT website to know more about the product offer available for you.
“The specified fuel consumption and emission data have been determined according to the measurement procedures prescribed by law. Since 1st September 2017, certain new vehicles are already being type-approved according to the Worldwide Harmonized Light Vehicles Test Procedure (WLTP), a more realistic test procedure for measuring fuel consumption and CO2 emissions. Starting on September 1st 2018, the New European Driving Cycle (NEDC) will be replaced by the WLTP in stages. Owing to the more realistic test conditions, the fuel consumption and CO2 emissions measured according to the WLTP will, in many cases, be higher than those measured according to the NEDC. For further information on the differences between the WLTP and NEDC, please visit our web page http://www.seat.com/company/wltp-standard.html
We are currently still required by law to state the NEDC figures. In the case of new vehicles which have been type-approved according to the WLTP, the NEDC figures are derived from the WLTP data. It is possible to specify the WLTP figures voluntarily in addition until such time as this is required by law. They are intended exclusively as a means of comparison between different vehicle types. Additional equipment and accessories (e.g. add-on parts, different tyre formats, etc.) may change the relevant vehicle parameters, such as weight, rolling resistance and aerodynamics, and, in conjunction with weather and traffic conditions and individual driving style, may affect fuel consumption, electrical power consumption, CO2 emissions and the performance figures for the vehicle.)
For more information about official fuel consumption and CO2 emissions values in new passenger cars, check the “Guide to passenger cars for sale in Spain, showing CO2 consumption and emissions”, available at all dealerships and on the webpage of the Institute for Diversification and Saving of Energy (http://coches.idae.es/PDF/GuiaFinalN.pdf.)“
